Wireless communication technology is undergoing an important shift from “improving device performance” to “optimizing the propagation environment”. Over the past few decades, wireless network development has mainly relied on continuous improvements in base stations, antennas, and terminal equipment, while the environment through which wireless signals propagate has always been regarded as an uncontrollable factor that can only be compensated for through algorithms.
As 5G networks mature and research on key 6G technologies advances, high-frequency communications such as millimeter wave and terahertz are becoming important development directions for future wireless systems. However, although high-frequency signals offer higher data rates, they are more susceptible to obstacles such as buildings, trees, and the human body, significantly reducing coverage. Traditional approaches that rely on adding more base stations are no longer able to balance network performance, construction cost, and energy efficiency.
Against this backdrop, metamaterials are gradually becoming an important research direction in wireless communications. They can not only change the way electromagnetic waves propagate, but also enable environmental infrastructure such as buildings, walls, and roads to participate in wireless signal control, thereby building smarter and more efficient communication networks and providing new technical paths for future 6G infrastructure.
What Are Metamaterials
Metamaterials are a class of functional materials that obtain special electromagnetic properties through artificially designed microstructures; their performance comes mainly from their internal structure, not the chemical composition of the material itself.
The reflection, refraction, transmission, and absorption capabilities of traditional materials for electromagnetic waves are determined by their natural physical properties. Metamaterials, however, can achieve more flexible control of electromagnetic waves by designing sub-wavelength periodic structures, for example:
This designability allows metamaterials to break through the limitations of traditional materials in electromagnetic control, providing new implementation methods for wireless communications.
Why high-frequency communications need metamaterials
As wireless communications move to higher frequency bands, network capacity continues to increase, but propagation characteristics also change significantly.
Although millimeter wave and terahertz bands have larger continuous spectrum resources that can support higher rates, lower latency, and more device connections, their propagation distance is short, diffraction capability is weak, and they are extremely sensitive to obstructions.
In real-world environments, buildings, glass curtain walls, metal structures, and human movement can all cause rapid signal attenuation or even complete blockage, creating large coverage blind zones.
Traditional networks usually improve coverage by increasing base station density and deploying more relay nodes, but this approach not only has high construction costs, but also continuously increases energy consumption and network O&M complexity.
Therefore, new-generation wireless communications are exploring another approach——actively controlling the wireless propagation environment, rather than relying only on transmitter and receiver performance improvements.
It is precisely under this demand that metamaterials demonstrate important value.
Reconfigurable intelligent surfaces driving wireless environment intelligence
Currently, one of the most representative applications of metamaterials is the Reconfigurable Intelligent Surface (RIS).
RIS consists of a large number of programmable metamaterial elements, each of which can dynamically adjust its own electromagnetic characteristics, changing the direction of wireless signal propagation in real time under electronic control.
Unlike ordinary walls, which can only reflect wireless signals at a fixed angle, RIS can actively adjust reflection angles based on network requirements, achieving more precise beam control.
Its main advantages include:
For example, in complex environments such as large office buildings, airports, stadiums, and industrial parks, RIS can reconstruct wireless propagation paths using walls, columns, or ceilings, significantly improving coverage without adding large numbers of base stations.
In the future, RIS is expected to become an important part of smart buildings, enabling communication networks to evolve from two-dimensional coverage to three-dimensional intelligent propagation systems.
Metamaterials promoting the development of new antenna technologies
Beyond environmental control, metamaterials are also driving innovation in wireless antenna design.
Traditional massive MIMO systems require antenna elements to maintain a certain spacing to avoid mutual coupling that degrades performance, which limits the miniaturization of antenna arrays.
Novel electromagnetic structures built with metamaterials can break this limitation, allowing antenna elements to be arranged more densely while maintaining high radiation efficiency.
This technology further gave rise to the concept of holographic MIMO (HolographicMIMO).
Holographic MIMO does not rely on a large number of independent antennas. Instead, it treats the entire metamaterial surface as a continuous radiating element, controlling the electromagnetic response of the whole surface in real time through software to achieve finer beamforming and spatial resource scheduling.
Compared with traditional arrays, holographic MIMO has the following characteristics:
As 6G moves to the terahertz band, this continuous electromagnetic aperture technology will become important support for high-frequency communications.
Metamaterials enabling wireless sensing convergence
Future wireless networks will not only handle communications, but also need environmental sensing capabilities.
Metamaterials can achieve integrated communication and sensing design.
Metasurface-based sensors can detect changes in temperature, humidity, pressure, vibration, and certain chemical substances by sensing tiny variations in ambient electromagnetic characteristics.
Because no complex power supply system is needed, such sensors feature:
Combined with ambient wireless signals, they can build large-scale low-power IoT networks, providing long-term stable data collection for smart cities, industrial monitoring, warehousing and logistics, and agricultural monitoring.
This direction of communication-sensing integration is also one of the important technical characteristics of 6G.
Optimizing spectrum resource utilization efficiency
Wireless spectrum resources are becoming increasingly scarce, making spectrum utilization improvement an important goal for future networks.
Metamaterials can be used to design high-performance filters, frequency-selective surfaces, and intelligent electromagnetic control devices, achieving more precise frequency control.
Compared with traditional filters, metamaterial devices usually have:
This means future wireless systems can distinguish signals in adjacent bands more efficiently, reducing spectrum conflicts and increasing overall network capacity.
Important value for smart cities and the industrial internet
As digital infrastructure continues to improve, metamaterials will play important roles across multiple industries.
In smart city construction, reconfigurable intelligent surfaces can improve network coverage in areas such as roads, underground spaces, and transportation hubs, providing stable communication environments for autonomous driving and intelligent transportation.
In the industrial internet, large factories typically contain large amounts of metal equipment and complex structures that easily cause wireless signal reflection and blockage. Metamaterials can improve propagation conditions in complex industrial environments, increase device connection stability, and provide reliable communications support for industrial automation, robot collaboration, and intelligent manufacturing.
In applications such as extended reality (XR), digital twins, and remote collaboration, high-quality wireless connections also depend on more stable, low-latency propagation environments, and metamaterials are precisely able to meet the growing network needs of these emerging services.
Technology development still facing multiple challenges
Although metamaterials show broad development prospects, a series of key issues still need to be resolved before large-scale commercialization.
First, the manufacturing cost of large-area metamaterial devices still has room to decrease. Achieving scalable, low-cost production is an important foundation for industrialization.
Second, RIS and other devices need deep collaboration with existing wireless networks, including network control, resource scheduling, and real-time optimization algorithms, all of which require more complete software system support.
In addition, interconnectivity between equipment from different vendors also requires unified technical specifications and interface standards to ensure future network compatibility and scalability.
As the industry chain continues to mature, these problems are being gradually solved, and related technologies have entered the engineering validation and pilot deployment stage.
Metamaterials will become an important part of future wireless infrastructure
Wireless communications are developing from “device intelligence” to “environment intelligence”.
Metamaterials give infrastructure such as buildings, walls, and roads the ability to actively control electromagnetic wave propagation, gradually transforming the communication environment from a passive propagation medium into an important part of the network. This brand-new network architecture not only improves coverage quality, reduces energy consumption, and improves spectrum utilization, but also supports the deep integration of communications, sensing, and computing, providing a new technical foundation for the development of 6G networks.
In the future, as key technologies such as reconfigurable intelligent surfaces, holographic MIMO, and intelligent electromagnetic control mature, metamaterials are expected to become an important part of next-generation wireless infrastructure, playing an increasingly important role in smart cities, the industrial internet, autonomous driving, the Internet of Things, and immersive digital applications, while driving wireless communication networks toward greater intelligence, efficiency, and sustainability.
